Carling
Technologies
?
D-Series Single Pole Toggle Switches
D-Series Single Pole Toggle Switches
The D-Series single pole compact high current toggle
switches are ideal for applications with back panel size
constraints. These switches feature self-cleaning contacts
and ratings up to 20A 125VAC, 10A 250VAC, 1 1/2 HP
125-250VAC. With an economical double insulated all-
nylon construction, these switches figure prominently in
the Environmental Controls, Marine, Food Service,
Vacuum Cleaner and various other general purpose mar-
kets with stringent current carrying requirements.
.156[3.96] DIA
Dielectric Strength
UL/CSA: 1000V - live to dead
metal parts & opposite polarity
TUV: 4000V - live to dead metal
parts; 750V - across open
contacts
Electrical Life
50,000 cycles
Mechanical Life
100,000 cycles
Operating Temperature
32°F to 185°F (0°C to 85°C)
.375[9.52]
.069[1.75] DIA
6.000[152.4]
.250[6.35]
.250[6.35]
.500[12.70]
.687[17.44]
KEYWAY
.072[1.82]
X
.038[.965] DP
SOLDER LUG
.250 TAB (Q.C.)
TERMINAL TYPE
INTEGRATED WIRE LEAD
(no exposed conductors)
.280[7.11]
.687[17.44]
.500[12.70] DIA
.062[1.57]
.376[9.55]
.500[12.70] DIA
.375[9.52]
.500[12.70] DIA
1.000[25.40]
.588[14.93]
MOUNTING HOLE
.038[9.65]
WITH KEYWAY
.125[3.17] DIA
WITH LOCKING RING
DA221 - P - B - B
1
Base Part Number
1 BASE PART NUMBER: SERIES/CIRCUITRY/RATING/TERMINATION
2
Actuator
Style
3
Actuator
Color
2 ACTUATOR STYLE
4
Bushing
Color
10A 250VAC, 20A 125VAC, 1 1/2 HP 125-250VAC
B
bat
P
paddle
solder .250 wire
OFF-NONE-ON
ON-NONE-ON
lug tab leads
DA220 DA221 DA225
DB220 DB221 DB225
3 ACTUATOR COLOR 2
B black
W
white
ON-OFF-ON
DC220 DC221 DC225
4 BUSHING COLOR 2
5A 250VAC, 10A 125VAC, 1/2 HP 125-250VAC,
B
black
W
white
4(4) 250VACμ TUV approved
wire
leads
ON-NONE-OFF
NOTES
DA945 1
1
2
Available with wire leads and ON-OFF circuit only.
Additional colors available. Please consult factory.
www.carlingtech.com
29
